The basic specifications
Bare machine size: 93 * 93 * 148 cm
Net weight/gross weight/Taiwan: 365 g / 435 g/PCS
Gross weight/box: 18.5 KG
Box size: 96 * 96 * 96
Carton size: 48 * 39.5 * 32 cm
PCS/box: 40
Track: 2.0 CH
Control: 4 button control
Audio parameters
Speaker: Φ 67 mm 3 Ω 5 w
Output power: 1 * 5 w
Signal to noise ratio: 80 db or higher
Frequency response range: 100 hz - 20 KHZ
Functional description
Patent no. : 201530384989.6
Bluetooth device name: Q9
Bluetooth parameters: build glory 6631 + EDR specification
Stereo audio transmission protocol (A2DP V1.2)
Hands-free protocol (HSP V1.2 HFP V1.5)
Wireless connection distance up to 10 meters
U disk, U disk storage MP3 songs support
TF card: support play the TF card store MP3 songs
LINE IN: support all external terminal 3.5 mm audio input
FM: support FM channel automatically
Electric performance parameters
The charger: DC + 5 v, 500 ma
Battery: 1200 ma lithium battery
Horn: 2.5 -inch 16 core magnetic double high frequency
Colors: red, blue, white and black
